기술개요
- 개발현황
- 제조 및 품질 공정도
- 시험 및 생산설비
- 2023 Antenna 권선 장비 개발/ 차량용 USB 조립 장비 개발
- 2022 Shield Can Assembly개발
- 2021 Automotive Motor Pin Contactor 개발
- 2020 SMD Plate Contactor 개발
- 2019 Automotive Antenna 개발
- 2019 Side Contact Connector 개발
- 2015 SMD Gasket 및 양면 절연 Shield Can 개발
- 2014 Dome S/W 개발
-
2013
Box-type Antenna Contact 개발
SMD Pan Nut 개발
- 2012 방수 SMD Dome S/W 개발
- 2011 Antenna Contact 개발
- 2010 Rechargeable Charger 개발
- 2009 내측절연 Shield Can 개발
- 2008 SMD Dome Switch/RF Cable Clip 개발
- 2007 Shield Can Clip 양산 개시
- 2006 Shield Can Clip 개발
- 2004 Card Edge Connector 개발
- 2000 0.5/0.8mm Board To Board Connector 개발
- 1995 1.27/2.0mm Board To Board Connector 개발
생산 공정 및 생산 CAPA 현황
PROCESS
-
STAMPING PROCESS
-
PACKING PROCESS TAPE & REEL / TRAY
-
SHEILD CAN PACKING
CAPABILITY
| ITEM | CAPACITY / MONTH | WORKING RATE(%) |
|---|---|---|
|
CLIP SHIELD CLIP, CONTACT, CABLE CLIP |
200,000,000 EA | 50% |
| SHIELD CAN | 20,000,000 EA | 45% |
| CONNECTOR | 600,000EA | 30% |
| SMD PAN NUT | 12,000,000EA | 80% |
| PLATES | 30,000,000EA | 70% |
| INSERT MOLDING(VINA) | 1,200,000EA | 50% |
생산 설비 현황
EQUIPMENT
LINE UP
| PRODUCTION LINE | CAPACITY / MONTH |
|---|---|
| PRESS STAMPING M/C (40TON~200TON) |
POCONS 16 , POCONSVINA 27 KH19 |
| PACKING M/C | T&R 32(VINA 4) TRAY 6 |
| PIN AUTO M/C | 1 |
| INSERTMOLDING M/C(60TON) | POCONSVINA 4 |
| INSERT MOLDING M/C(150TON) | POCONSVINA 2 |
| CUTTING M/C | 2 |
| ULTRA SONIC CLEANER | 1 |
| GRINDER | 2 |
| AUTOMATIC CHECK M/C | 3 |
| COIL WINDING M/C | POCONS VINA 4 |
MAIN PROCESS
-
PRESS STAMPING M/C
-
AUTO PACKING M/C
-
AUTO STAMPING M/C
-
INJECTION M/C
신뢰성 장비 현황
* (VINA 설치대수)
| USE | EQUIPMENT | Q’TY |
|---|---|---|
| Environment Test M/C | Thermal Shock Chamber | 1(1) |
| Reflow Tester | 1 | |
| Temp/Humidity Chamber | 1(1) | |
| Salt-Water Spray Tester | 1(1) | |
| XRF-Analysis Device | 1(1) | |
| Plating Thickness Measuring M/C | 1(1) | |
| Analysis Device | High-Speed Polishing M/C | 1 |
| High-Speed Cutting M/C | 1 | |
| Inspection M/C | 3-Dimensional Measuring M/C | 1 |
| Illumination Photometry/Shape Measuring M/C | 1 | |
| Video M/S | 5(5) | |
| Vision Inspection Equipment | 2 | |
| Tensile Tester | 2 | |
| Erosion Measuring Instrument | 1 | |
| Hardness Measuring Instrument | 1 | |
| Projector | 3 | |
| Switch Feeling Tester | 2(1) | |
|
Electricity/Electron Measuring M/C |
Oscillo Scope | 1 |
| Milliohm Meter | 1 | |
| DC Power Supply | 1 | |
| Withstand Voltage/Insulation Resistor | 1 |
